Spectre: when the speed tricks of processors leak secrets

On January 3, 2018, Google Project Zero and, independently, researchers from several universities and companies made public a flaw in the design of modern processors. Called Spectre, it lets a program trick the processor into revealing memory it should never be able to read, such as data of the operating system or of other programs. The affected processors from Intel, AMD and Arm are used in billions of devices, and according to Google, the flaw had been in most computers for nearly 20 years.

Spectre is not a bug in one product that a single update removes. It lies in the way processors work, so the fixes had to come from many sides at once.

How it worked

To stay fast, a modern processor does not wait until it knows which way a program will go next. It guesses and works ahead. This is called speculative execution. If the guess was wrong, the processor throws the results away. But it leaves traces in its cache, a small and fast memory that keeps recently used data close at hand.

Spectre comes in two variants. The first abuses a check that careful programs make: before they read entry number x of a list, they check that x lies inside the list. The attacker first trains the processor to expect that the check passes. Then the attacker asks for an entry far outside the list. While the check is still running, the processor guesses, reads a secret byte beyond the end of the list and uses it to load a piece of memory into the cache. The result is thrown away. But the attacker measures how fast different pieces of memory respond, sees which one was loaded and works out the secret byte from that.

In the second variant, the attacker trains the processor’s guesses for jumps in another program, such as the operating system or a hypervisor, the software that runs virtual machines in a cloud. The victim then briefly runs code fragments chosen by the attacker, which leak data in the same way.

The attacker’s program must already run on the same device, the attack is hard to carry out, and it can read data but not change it. That is why the US National Vulnerability Database scores Spectre at only 5.6 of 10. Still, the attack worked in Google’s tests. With normal user rights, it read the memory of the kernel, the core of the operating system, at around 2,000 bytes per second. From inside a virtual machine, it read the kernel memory of the host machine at around 1,500 bytes per second.

Reach and the cost of the fixes

According to the researchers, almost every system is affected: desktops, laptops, cloud servers and smartphones. Google Project Zero’s test attacks ran on processors from all three makers: an Intel Xeon, two AMD processors and the Arm processor of a Nexus 5X phone.

Has Spectre been used in real attacks? The researchers’ answer is: “We don’t know.” No attack has been confirmed, and neither of the two Spectre CVEs is on the list of exploited vulnerabilities kept by the US agency CISA. In February 2021, a working exploit for Linux and Windows, a program that carries out the attack, was uploaded to VirusTotal, a service that checks files for malware, a security researcher reported. That is a ready-made tool, not an observed attack.

The price of Spectre was paid in speed. Some fixes stop processors from guessing certain jumps or make them clear their guesses more often, and that costs time. Most published measurements cover the fixes for Spectre and for Meltdown, a related processor flaw made public alongside it, together.

Microsoft measured single-digit slowdowns on Windows 10 PCs with processors from around 2016 or newer. Older PCs and Windows Server slowed down more, especially when they read and wrote a lot of data. Google reported that it rolled out its fixes across its cloud without customers noticing: it received no support tickets about them.

The fix: many small repairs

Google Project Zero reported the flaw to Intel, AMD and Arm on June 1, 2017. A joint publication was planned for January 9, 2018, but Google went public six days early because reports had already appeared. According to Google, all of its cloud services had protections against all known variants by December 2017.

The fixes came from several sides, starting on January 3, 2018: updates for operating systems and browsers, new techniques in compilers, the tools that turn source code into programs, and microcode updates, which change the built-in control program of the processor. Microsoft released its first updates on January 3. Six days later, patches for 41 of the 45 Windows editions it supported were available through Windows Update.

Retpoline rewrites jumps in a program so that the processor’s guesses end up in a harmless loop. Google says it fully protects against the second variant without affecting its customers’ performance, and the Linux kernel turns it on by default on vulnerable processors. Newer processors have a hardware feature called enhanced IBRS, which limits the guessing of jumps; the kernel documentation describes it as more efficient than retpoline.
